Caterpillar 2PD7000 Specs
Quick-reference specifications for the Caterpillar 2PD7000 forklift, taken from the manufacturer’s spec sheet.
- Capacity at rated load center
- 7,000 lb3,500 kg
- Gradeability loaded at 1 mph (1.6 km)
- 20.6 %
Performance 10 specs
| Capacity at rated load center | 7,000 lb (3,500 kg) |
|---|---|
| Capacity at load center – distance | 24 in (500 mm) |
| Tilt forward / backward | 6° / 10° |
| Minimum outside turning radius | 96.0 in (2,440 mm) |
| Speeds travel loaded / empty | 11.0 / 11.5 mph (16.5 / 18.0 km/h) |
| Speeds lift speed loaded / empty | 80 / 85 fpm (410 / 430 mm/s) |
| Speeds lowering speed loaded / empty | 98 / 98 fpm (500 / 500 mm/s) |
| Gradeability loaded at 1 mph (1.6 km) | 20.6 % |
| Gradeability maximum loaded / empty | 40.6 / 14.9 % |
| Axle load with rated load front / rear (est.) | 15,500 / 2,130 lb (7,300 / 1,000 kg) |
Dimensions 12 specs
| Tire type | pneumatic |
|---|---|
| Lift with standard maximum fork height | 131 in (3,330 mm) |
| Two-stage mast free fork height | 5.9 in (150 mm) |
| Forks thickness x length x width | 2 x 5 x 42 in (50 x 125 x 1,070 mm) |
| Fork spacing out-to-out minimum / maximum | 9.8 / 39.4 in (250 / 1,000 mm) |
| Overall dimensions length to fork face | 110 in (2,790 mm) |
| Overall dimensions width with standard tires | 51.0 in (1,300 mm) |
| Overall dimensions width with optional duals | 67.5 in (1,710 mm) |
| Overall dimensions height with lowered mast | 91.0 in (2,310 mm) |
| Overall dimensions height seat height | 47.7 in (1,210 mm) |
| Overall dimensions height to top of overhead guard | 84.5 in (2,140 mm) |
| Overall dimensions height with extended mast | 180 in (4,570 mm) |
Weight 1 spec
| Axle load without load front / rear (est.) | 3,890 / 6,500 lb (1,760 / 2,890 kg) |
|---|
