Forklift · Caterpillar
Caterpillar EC30LN2 Specs
Quick-reference specifications for the Caterpillar EC30LN2 forklift, taken from the manufacturer’s spec sheet.
- Capacity at rated load center
- 6,500 lb2,950 kg
- Gradeability – loaded at 1 mph (1.6 kmh) (36 volt)
- 20 %
Performance 8 specs
| Capacity at rated load center | 6,500 lb (2,950 kg) |
|---|---|
| Load center — distance | 24 in (600 mm) |
| Tilt – forward / backward | 5.0° / 5.0° |
| Drawbar pin height | 11 in (282 mm) |
| Minimum outside turning radius | 79.5 in (2,020 mm) |
| Lowering speed – loaded / empty | 98 / 89 fpm (0.50 / 0.45 m/s) |
| Axle load – with rated load (front / rear) | 15,190 / 2,405 lb (6,890 / 1,090 kg) |
| Axle load – without rated load (front / rear) | 3,935 / 7,155 lb (1,785 / 3,245 kg) |
Dimensions 21 specs
| Tire type – cushion, solid pneumatic | cushion |
|---|---|
| Lift height | 131 in (3,345 mm) |
| Overall height with mast raised | 180 in (4,566 mm) |
| Free lift | 5.3 in (135 mm) |
| Forks – length x width x thickness | 42 x 4.9 x 1.8 in (1,070 x 125 x 45 mm) |
| Fork spacing – out-to-out minimum / maximum | 11.2 / 37.8 in (285 / 960 mm) |
| Overall length (with 42″ long forks) | 130.9 in (3,325 mm) |
| Length to fork face (includes fork thickness) | 88.8 in (2,255 mm) |
| Overall width | 43.5 in (1,103 mm) |
| Height to top of lowered mast | 88.0 in (2,230 mm) |
| Seat height to SIP | 49.5 in (1,257 mm) |
| Height to top of overhead guard | 87.0 in (2,210 mm) |
| Tire size – front | 21 x 8 x 15 in (533 x 203 x 381 mm) |
| Tire size – rear | 16 x 6 x 10.5 in (406 x 152 x 267 mm) |
| Wheelbase | 54.3 in (1,380 mm) |
| Track width – front (center of tires) | 35.4 in (900 mm) |
| Track width – rear (center of tires) | 34.8 in (884 mm) |
| Ground clearance – at lowest point at mast | 3 in (77 mm) |
| Ground clearance – at center of wheelbase | 4.9 in (124 mm) |
| Service brakes | foot-operated, hydraulic |
| Parking brakes | hand-operated, mechanical |
Power / Engine 7 specs
| Gradeability – loaded at 1 mph (1.6 kmh) (36 volt) | 20 % |
|---|---|
| Gradeability – loaded at 1 mph (1.6 kmh) (48 volt) | 21 % |
| Empty – with minimum weight battery | 11,090 lb (5,030 kg) |
| Battery type | lead-acid |
| Battery weight, minimum | 3,100 lb (1,410 kg) |
| Battery weight, maximum | 3,970 lb (1,800 kg) |
| Battery compartment size, maximum | 34.4 x 39.5 x 23.3 in (875 x 1,003 x 592 mm) |
Hydraulics / Fluids 1 spec
| Drive / hydraulic controls | AC transistor |
|---|
