Forklift · Caterpillar
Caterpillar GP45N Specs
Quick-reference specifications for the Caterpillar GP45N forklift, from the manufacturer’s spec sheet and published specifications.
Performance 10 specs
| Rated speed to DIN | 70 020 |
|---|---|
| Load Capacity | 9,000 lb (4,500 kg) |
| Lift Height | 10.8 ft (3.3 m) |
| Travel Speed with Load | 22.0 km/h |
| Travel Speed without Load | 22.5 km/h |
| Hoisting Speed with Load | 0.57 m/s |
| Hoisting Speed without Load | 0.60 m/s |
| Lowering Speed with Load | 0.5 m/s |
| Maximum Climbing Ability | 27% |
| Turning Radius | 8.96 ft (2.73 m) |
Dimensions 4 specs
| Fork carriage to DIN | 15 173 A / B / no |
|---|---|
| Overall Width | 77.0 in (1,965 mm) |
| Construction Height (mast lowered) | 91.3 in (2,320 mm) |
| Load Center | 19.7 in (500 mm) |
Weight 1 spec
| Truck Weight (without load) | 13,820 lb (6,270 kg) |
|---|
Power / Engine 5 specs
| Engine Type | GCT GK45 |
|---|---|
| Engine Displacement | 4.5 L |
| Number of Cylinders | 6 |
| Engine Power | 97 hp (72 kW) |
| Maximum Torque | 288 Nm |
Hydraulics / Fluids 2 specs
| Maximum Operating Pressure for Attachments | 191 bar |
|---|---|
| Oil Flow for Attachments | 80 L/min |
