Forklift · Caterpillar
Caterpillar NSP12N2 Specs
Quick-reference specifications for the Caterpillar NSP12N2 forklift, from the manufacturer’s spec sheet and published specifications.
- Maximum Gradeability (with load / without load)
- 8% / 15%
Performance 7 specs
| V / Ah | 24 / 150-230 |
|---|---|
| Nominal Load Capacity | 2,645 lb (1.2 t) |
| Lifting Speed (with load / without load) | 0.12 m/s / 0.26 m/s |
| Lowering Speed (with load) | 0.35 m/s |
| Maximum Gradeability (with load / without load) | 8% / 15% |
| Turning Radius | 4.74 ft (1.447 m) |
| Lifting Height | 15.42 ft (4.7 m) |
Dimensions 4 specs
| Transport Length | 6.23 ft (1.9 m) |
|---|---|
| Transport Width | 2.62 ft (0.8 m) |
| Transport Height | 8.17 ft (2.49 m) |
| Wheelbase | 3.95 ft (1.205 m) |
Weight 2 specs
| Vehicle Weight | 2,656 lb (1.205 t) |
|---|---|
| Battery Weight | 467 lb (0.212 t) |
Power / Engine 4 specs
| Battery – Pedestrian / Stand-on | 1600 |
|---|---|
| Traction Motor Output | 1.34 hp (1 kW) |
| Hoist Motor Output | 2.95 hp (2.2 kW) |
| Battery Voltage/Capacity | 24 V / 250 Ah |
