Caterpillar PD8000 Specs
Quick-reference specifications for the Caterpillar PD8000 forklift, taken from the manufacturer’s spec sheet.
- Capacity
- 8,000 lb4,000 kg
- Gradeability loaded at 1 mph (1.6 km)
- 30.5 %
Performance 11 specs
| Capacity | 8,000 lb (4,000 kg) |
|---|---|
| Tilt forward / backward | 6° / 10° |
| Minimum outside turning radius | 101.0 in (2,580 mm) |
| Speeds travel speed loaded / empty | 13.5 / 14.0 fpm (22.0 / 22.5 km/h) |
| Speeds lift speed loaded / empty | 100 / 110 fpm (0.57 / 0.64 m/s) |
| Speeds lowering speed loaded / empty | 94 / 75 fpm (0.52 / 0.47 m/s) |
| Gradeability loaded at 1 mph (1.6 km) | 30.5 % |
| Gradeability maximum loaded | 42.5 % |
| Axle load with rated load front / rear | 18,950 / 2,100 lb (8,961 / 960 kg) |
| Brakes service | foot, hydraulic |
| Brakes parking | hand, mechanical |
Dimensions 20 specs
| Tire type | pneumatic |
|---|---|
| Lift with standard maximum fork height (top of fork) | 132 in (3,300 mm) |
| Two-stage mast free fork height | 5.9 in (150 mm) |
| Fork spacing out-to-out minimum / maximum | 12.6 / 46.6 in (320 / 1,184 mm) |
| Overall dimensions length to fork face | 118 in (3,000 mm) |
| Overall dimensions width with standard tires | 55.5 in (1,415 mm) |
| Overall dimensions width with optional duals | 77.5 in (1,780 mm) |
| Overall dimensions height with lowered mast | 91.5 in (2,320 mm) |
| Overall dimensions height seat height | 42.6 in (1,082 mm) |
| Overall dimensions height to top of overhead guard | 90.5 in (2,296 mm) |
| Overall dimensions height with extended mast | 180.0 in (4,570 mm) |
| Tire size front, standard | 8.25x15x14PR |
| Tire size front, optional duals | 8.25x15x14PR |
| Tire size rear | 7.00x12x12PR |
| Wheelbase | 73.0 in (1,850 mm) |
| Tread width front, standard tires | 46.5 in (1,175 mm) |
| Tread width front, optional duals | 57.0 in (1,445 mm) |
| Tread width rear tires | 46.5 in (1,180 mm) |
| Ground clearance at lowest point at mast | 5.9 in (150 mm) |
| Ground clearance at center of wheelbase | 8.9 in (227 mm) |
Weight 1 spec
| Axle load without load front / rear | 5,800 / 7,250 lb (2,632 / 3,288 kg) |
|---|
Power / Engine 6 specs
| Engine model | Mitsubishi S6S |
|---|---|
| Engine continuous output S.A.E. gross | 77 HP (58 kW) |
| Engine maximum torque S.A.E. gross | 192 lb-ft (260 N-m) |
| Engine cylinder / displacement | 6 / 275 cu in (6 / 4.5 L) |
| Transmission type | powershift |
| Battery volts | 12 |
