Crown RR5010-35 Specs

Quick-reference specifications for the Crown RR5010-35 forklift, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Performance 8 specs

Load Capacity Max	3500 lb
Load Center Fork Face to Load CG	24 in
Carriage Tilt F°/B°	3/4 degree
Speed Travel Forks First (E/L)	5.7/5.7 mph
Speed Lift Empty/Loaded	52/37 fpm
Speed Lower Empty/Loaded	85/90 fpm
Brakes Drive	Elec Release/Mech Applied
Brakes Parking	Elec Release/Mech Applied

Dimensions 18 specs

Tire Type Load/Caster/Drive	Poly/Poly/Poly
Mast Type	Hi-Visibility TT
ForksStandardLxWxT	36 x 4 x 1.75 in
Forks Optional Lengths	30, 39, 42, 45, 48 in
Headlength Comp’t A	47.16 in
Headlength Comp’t B	49.28 in
Headlength Comp’t C	51.28 in
Inside Straddle Width In 1 inch increments	34 – 50 in
Tires Size – Drive/Caster	13 x 5.5/8 x 4 in
Wheelbase (Standard Wheel) Comp’t A	52.12 in
Wheelbase (Standard Wheel) Comp’t B	54.24 in
Wheelbase (Standard Wheel) Comp’t C	56.24 in
Suspension Drive	Articulated
Lift Height 198 inch – Free Lift	41 in
Lift Height 198 inch – Guard Height	89 in
Lift Height 198 inch – Overall Collapsed Height	89 in
Lift Height 198 inch – Overall Extended Height	246 in
Minimum Straddle OD	42 in

Weight 3 specs

Min Weight/Max Amp Comp’t A	1300 lb/1085 amp
Min Weight/Max Amp Comp’t B	1600 lb/1085 amp
Min Weight/Max Amp Comp’t C	1880 lb/1020 amp

Power / Engine 6 specs

Power	24 Volts
Speed Travel Power Unit First (E/L)	6.3/6.3 mph
Battery Type	Lead Acid
Max Battery Size Comp’t A	12.19×38.38×31 in
Max Battery Size Comp’t B	14.25×38.38×31 in
Max Battery Size Comp’t C	16.25×38.38×31 in
