Doosan GC55C-5 Specs
Quick-reference specifications for the Doosan GC55C-5 forklift, taken from the manufacturer’s spec sheet.
- Max. gradeability Loaded at 1.0 mph (1.7km / h)
- 21 %
Performance 12 specs
| Load Capacity at rated load center | 5,500 kg |
|---|---|
| Load Center | 600 mm |
| Free Lift | 160 mm |
| Fork Spacing (Min x Max) | 340 x 1,290 mm |
| Tilt of Mast Forward / Backward | 5 / 6 deg |
| Turning Radius Minimum outside | 2,630 mm |
| Travel Speed Loaded / Unloaded | 21 / 22 km/h |
| Lifting Speed Loaded / Unloaded | 450 / 500 mm/s |
| Lowering Speed Loaded / Unloaded | 480 / 440 mm/s |
| Max. drawbar pull Loaded at 1.0 mph (1.6km / h) | 2,696 kg |
| Max. gradeability Loaded at 1.0 mph (1.7km / h) | 21 % |
| Brakes Service | foot / hyd |
Dimensions 14 specs
| Tire type | C |
|---|---|
| Max. Fork Height with STD 2-stage mast | 2,630 mm |
| Forks Length x Width x Thickness | 1,220x150x50 mm |
| Length to Fork Face | 3,010 mm |
| Overall Width | 1,420 mm |
| Overall Dimensions Mast Lowered Height | 2,185 mm |
| Mast Extended Height | 4,065 mm |
| Overhead Guard Height | 2,155 mm |
| Seat Height | 1,125 mm |
| Load Moment Center | 515 mm |
| Tires Size, Front | 22x12x16 |
| Tread Width Front / Rear | 1,116 / 1,044 mm |
| Ground Clearance Loaded at the lowest point | 130 mm |
| Loaded at center of wheelbase | 130 mm |
Weight 3 specs
| Total Service Weight, Unloaded | 7,340 kg |
|---|---|
| Axle Load Loaded, Front / Rear | 11,330 / 1,510 kg |
| Unloaded, Front / Rear | 2,400 / 4,940 kg |
Power / Engine 7 specs
| Power type | LPG |
|---|---|
| Battery Voltage / Ampere | 12 / 75 V/AH |
| Engine Rated Power (DIN) HP/rpm | 93 / 2,450 |
| KW/rpm | 69 / 2,450 |
| Maximum Torque kgm/rpm | 31/ 1,400 |
| Cylinders / Displacements CC | 6 / 4,294 |
| Transmission Type | powershift |
Hydraulics / Fluids 1 spec
| Hydraulic Pressure System | 230 bar |
|---|
