- Hyster H5.5FT
Forklift · Hyster
Hyster H5.5FT Specs
Quick-reference specifications for the Hyster H5.5FT forklift, from the manufacturer’s spec sheet and published specifications.
Performance 10 specs
| Powershift | 2-speed |
|---|---|
| Load distance, centre of drive axle to fork | x |
| Load Center | 600 mm |
| Travel Speed with Load | 18.1 km/h |
| Travel Speed without Load | 18.5 km/h |
| Hoisting Speed with Load | 0.48 m/s |
| Hoisting Speed without Load | 0.49 m/s |
| Lowering Speed with Load | 0.51 m/s |
| Lowering Speed without Load | 0.42 m/s |
| Turning Radius | 2.915 m |
Dimensions 5 specs
| Ground clearance, laden, below mast | m1 |
|---|---|
| Ground clearance, centre of wheelbase | m2 |
| Total Width | 1,450 mm (1.45 m) |
| Construction Height (Mast Lowered) | 2,300 mm (2.3 m) |
| Overall Width Options | 1,450 mm / 1,575 mm / 1,875 mm |
Power / Engine 6 specs
| Fuel consumption according to VDI cycle | l/h |
|---|---|
| Engine Type (Diesel) | QSB3.3 |
| Engine Power (Diesel) | 60 kW |
| Engine Type (LPG alt) | 4.3 L |
| Engine Power (LPG alt) | 77 kW |
| Current Engine Option | Kubota 3.8 L Diesel |
