Hyster H8.00XM-6 Specs
Quick-reference specifications for the Hyster H8.00XM-6 forklift, from the manufacturer’s spec sheet and published specifications.
- Maximum Gradeability
- 63%
Performance 10 specs
| Forks | H8.00XM-6, H9.00XM-6: |
|---|---|
| Mast tables – Add | 25 mm if optional 10.00 x 20 |
| Travel Speed (Laden) | 16.4 mph (26.4 km/h) |
| Travel Speed (Unladen) | 17.5 mph (28.1 km/h) |
| Hoisting Speed (Laden) | 0.46 m/s (90.5 ft/min) |
| Hoisting Speed (Unladen) | 0.52 m/s (102 ft/min) |
| Lowering Speed (Laden) | 0.50 m/s (98 ft/min) |
| Lowering Speed (Unladen) | 0.48 m/s (94 ft/min) |
| Maximum Gradeability | 63% |
| Turning Radius | 12.8 ft (3.914 m) |
Dimensions 4 specs
| Overall Width | 8.1 ft (2,463 mm) |
|---|---|
| Construction Height (Chassis Height) | 9.9 ft (3,015 mm) |
| Lifting Height | 17.7 ft (5.4 m) |
| Load Center Distance | 23.6 in (600 mm) |
Weight 2 specs
| Total Vehicle Weight | 27,329 lb (12,389 kg) |
|---|---|
| Counterweight | 6,768 lb (3,070 kg) |
Power / Engine 6 specs
| Engine Model | QSB 6.7 |
|---|---|
| Engine Power | 156 hp (117 kW) |
| Engine Displacement | 6.7 L |
| Number of Cylinders | 6 |
| Cylinder Bore x Stroke | 107 x 124 mm |
| Maximum Torque | 673 Nm (496 ft-lb) @ 1500 rpm |
Hydraulics / Fluids 4 specs
| Hydraulic Pump Displacement | 90 cc/rev |
|---|---|
| Hydraulic Pump Flow @ 2300 rpm | 196 L/min (51.7 gal/min) |
| Hydraulic Tank Capacity | 33 gal (125 L) |
| Total Hydraulic System Capacity | 42.3 gal (160 L) |
