Telehandler · JCB
JCB 508-66 Specs
Quick-reference specifications for the JCB 508-66 telehandler, taken from the manufacturer’s spec sheet.
- Maximum lift capacity
- 8000 lb
- Maximum lift height
- 66 ft
- Maximum forward reach
- 52 ft
Performance 3 specs
| Maximum lift capacity | 8000 lb |
|---|---|
| Maximum forward reach | 52 ft |
| Tires | 440 / 80-24 |
Dimensions 5 specs
| Maximum lift height | 66 ft |
|---|---|
| Overall height | 8.86 ft |
| Overall width over tires | 7.87 ft |
| Overall length to front carriage | 22.38 ft |
| Turn radius over tires | 13.45 ft |
Weight 1 spec
| Total weight (unladen) | 28627 lb |
|---|
Power / Engine 1 spec
| Gross power | 74 hp (55 kW) |
|---|
