Telehandler · JCB
JCB 555-260R Specs
Quick-reference specifications for the JCB 555-260R telehandler, from the manufacturer’s spec sheet and published specifications.
- Max Lift Capacity
- 12,125 lb5,500 kg
- Operating Weight
- 42,771 lb19,400 kg
Performance 6 specs
| Max reach | 21.4 m |
|---|---|
| Max Lift Capacity | 12,125 lb (5,500 kg) |
| Lift Capacity at Full Height | 4,409 lb (2,000 kg) |
| Lift Capacity at Full Reach | 661 lb (300 kg) |
| Road Speed | 24.85 mph (40 km/h) |
| Max Torque | 600 Nm @ 1500 RPM |
Dimensions 6 specs
| Max lift height | 25.5 m |
|---|---|
| Overall Length | 26.54 ft (8.09 m) |
| Overall Width | 8.04 ft (2.45 m) |
| Overall Height (Mast Lowered) | 10.10 ft (3.08 m) |
| Outside Turn Radius | 15.16 ft (4.62 m) |
| Ground Clearance | 1.15 ft (0.35 m) |
Weight 1 spec
| Operating Weight | 42,771 lb (19,400 kg) |
|---|
Power / Engine 2 specs
| Engine Power | 150 hp (112 kW) |
|---|---|
| Drive | 4-wheel drive, 3 steering modes |
Hydraulics / Fluids 1 spec
| Steering System | 4-wheel steer – 3 steering modes |
|---|
