JCB 66-40E Specs

Quick-reference specifications for the JCB 66-40E telehandler, taken from the manufacturer’s spec sheet.

Performance 4 specs

Lift height	13 ft 1 in
Free lift (standard)	5 ft 2 in
Height (boom extended)	15 ft 2 in
Height of overhead guard	7 ft 4 in
Height of operators seat	3 ft 6 in
Length to fork face	9 ft 10 in
Wheelbase	5 ft 11 in
Load centre	1 ft 8 in
Ground clearance (lowest point)	0 ft 6 in
Ground clearance (wheelbase centre)	0 ft 7 in
Fork carriage width	3 ft 11 in
Maximum width of machine	4 ft 3 in
