JCB S4550E Specs
Quick-reference specifications for the JCB S4550E telehandler, from the manufacturer’s spec sheet and published specifications.
- Platform Height
- 43 in1.1 m
- Max Working Height
- 51 ft 3 in15.8 m
- Gradeability
- 25%
Performance 13 specs
| Platformsize(LxWxH) | 2.64 x 1.15 x 1.1 |
|---|---|
| Raising speed (loaded) | 73-83 |
| Lowering speed (loaded) | 56-66 |
| Max Working Height | 51 ft 3 in (15.8 m) |
| Max Platform Height | 45 ft 3 in (13.8 m) |
| Load Capacity | 505 lb (230 kg) |
| Max Platform Occupants (indoor) | 2 persons |
| Gradeability | 25% |
| Max Driving Speed (stowed) | 2.8 mph (4.5 km/h) |
| Max Driving Speed (raised) | 0.5 mph (0.8 km/h) |
| Platform Extension Outreach | 3 ft (0.9 m) |
| Max Allowable Slope (front/back) | 3 degrees |
| Max Allowable Slope (side/side) | 1.5 degrees |
Dimensions 10 specs
| Platform Length | 104 in (2.64 m) |
|---|---|
| Platform Width | 45.3 in (1.15 m) |
| Platform Height | 43 in (1.1 m) |
| Overall Length (stowed, guardrail folded) | 9 ft (2.76 m) |
| Overall Width (stowed) | 4 ft 1 in (1.27 m) |
| Overall Height (stowed, guardrail unfolded) | 9 ft (2.2 m) |
| Ground Clearance (stowed) | 4 in (0.1 m) |
| Wheelbase | 87 in (2.22 m) |
| Turning Radius (outside) | 8 ft 5 in (2.56 m) |
| Solid Tyre Dimensions | 12 x 4.5 in (305 x 115 mm) |
Weight 1 spec
| Overall Weight | 7,921 lb (3,593 kg) |
|---|
Power / Engine 3 specs
| Charger Input Voltage | 100–240 VAc |
|---|---|
| Charger Output | 25 A |
| Power Unit | 6.1 hp (5 kW) |
Hydraulics / Fluids 1 spec
| Hydraulic System Pressure | 3,481 psi |
|---|
