JLG 10MSP Spec Sheet
Quick-reference specifications for the JLG 10MSP. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
Platform Capacity: 350-lb (160-kg)
Working Height 16-ft /: 4.88-m
Platform Height: 10-ft (3.05-m)
Platform Capacity 350-lb /: 159-kg
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Platform Height | 10-ft (3.05-m) |
|---|---|
| Platform Capacity | 350-lb (160-kg) |
| Platform Height (Elevated) 10-ft / | 3.05-m |
| Working Height 16-ft / | 4.88-m |
| Platform Capacity 350-lb / | 159-kg |
| Material Tray Capacity 250-lb / | 113-kg |
| Gradeability | 15% |
Dimensions
| Machine Width 32.5-in / | 82.5-cm |
|---|---|
| A. Machine Height 57-in / | 145-cm |
| B. Platform Width 20-in / | 49.5-cm |
| C. Platform Length 27-in / | 69-cm |
| D. Machine Width (With Bumpers) 32.5-in / | 82.5-cm |
| E. Machine Length 61-in / | 1.55-m |
| F. Ground Entry Height 13.75-in / | 35-cm |
| G. Ground Clearance 2-in / | 5-cm |
Weights & Electrical
| Batteries 4 Sealed | 210 amp-hr Maintenance Free (AGM) |
|---|---|
| Battery Charger | 25 Amp Automatic |
Powertrain & Systems
| Stowed Drive Speed 5 mph / | 8.0 km/h |
|---|---|
| Drive Speed (Lowered) 5.0 mph / | 8.0 km/h |
| Drive Speed (Elevated) 0.5 mph / | 0.8 km/h |
| Drive System | 4 Brush Direct Electric (Planetary Gear) |
