Linde E80-900 Specs

Quick-reference specifications for the Linde E80-900 forklift, taken from the manufacturer’s spec sheet.

Performance 20 specs

Load capacity/Load Q	8.0 t
Load centre distance c	900 mm
Axle centre to fork face x	750 mm
Service weight	15720 kg
Axle load with load, front/rear	21483 / 2237 kg
Axle load without load, front/rear	7983 / 7737 kg
Tyres	SE twin
Mast/fork carriage tilt, forward/backward a/b	5.0 / 7.5 °
Turning radius Wa	3205 mm
Travel speed, with/without load	16 / 16 km/h
Lifting speed, with/without load	0.3 / 0.46 m/s
Lowering speed, with/without load	0.56 / 0.45 m/s
Maximum tractive force, with/without load	43000 / 43000 N
Acceleration time, with/without load	7.2 / 6.8 s
Service brake	hydr./mech.
Drive motor rating S2 60 min	2x 10.5 kW
Lift motor rating at S3 15%	2x 21 kW
Operating pressure for attachments	265 + 5 bar
Oil flow for attachments	85 l/min
Sound pressure level LpAZ (at the driver’s seat)	<65 dB (A)

Wheelbase y	2400 mm
Track width, front b	1564 mm
Track width, rear b	1396 mm
Height of mast, lowered h	2885 mm
Free lift h	150 mm
Lift h	3050 mm
Height of mast, extended h	4447 mm
Height of overhead guard (cabin) h	2838 mm
Height of seat/stand on platform h	1705 mm
Towing coupling height h	858 mm
Overall length l	5533 mm
Length to fork face l	3733 mm
Overall width b1/b	2111 / 1654 mm
Fork dimensions DIN ISO 2331 s/e/l	70 x 200 x 1800 mm
Fork carriage to ISO 2328, class/type A, B	4A
Width of fork carriage b	2180 mm
Ground clearance, below mast m	220 mm
Ground clearance, centre of wheelbase m	210 mm
Aisle width for pallets 1000 × 1200 crossways Ast	5155 mm
Aisle width with pallet 800 x 1200 along forks Ast	5355 mm
Minimum pivoting point distance b	930 mm

Battery according to DIN 43531/35/36 A,B,C,no	43 536 / A
Battery weight (± 5%)	2785 kg
Power consumption according to VDI cycle	21 kWh/h
