Forklift · Linde
Linde P20 Specs
Quick-reference specifications for the Linde P20 forklift, taken from the manufacturer’s spec sheet.
Performance 11 specs
| Load capacity/Load Q | 2.0 t |
|---|---|
| Service weight | 630 kg |
| Axle load without load, front/rear | 350 / 280 kg |
| Tyres | rubber, SE, pneumatic, polyurethane C+PU/C |
| Turning radius Wa | 1080 mm |
| Travel speed, with/without load | 8 / 8 km/h |
| Tractive force, with/without load | 400 N |
| Maximum tractive force, with/without load | 1760 N |
| Service brake | Electro-magnetic |
| Drive motor, 60 minute rating | 1.5 kW |
| Type of drive control | LAC |
Dimensions 11 specs
| Wheelbase y | 907 mm |
|---|---|
| Tyre size, front | Ø 230 x 75 |
| Tyre size, rear | 2 x Ø 250 x 80 |
| Track width, front b | 418 mm |
| Track width, rear b | 480 mm |
| Height of seat/stand on platform h | 800 / 985 mm |
| Towing coupling height h | 276 mm |
| Rear overhang l | 253 mm |
| Overall length l | 1315 mm |
| Overall width b1/b | 600 mm |
| Ground clearance, centre of wheelbase m | 40 / 80 mm |
Power / Engine 2 specs
| Battery according to DIN 43531/35/36 A,B,C,no | 2PzS-B |
|---|---|
| Battery weight (± 5%) | 185 kg |
