Aerial Lift · Snorkel
Snorkel TM12E Specs
Quick-reference specifications for the Snorkel TM12E aerial lift, taken from the manufacturer’s spec sheet.
- Platform capacity (SWL)
- 500 lb
- Max. working height
- 18 ft
- Weight
- 2,240 lb
- Gradeability
- 25%
Performance 11 specs
| Max. working height | 18 ft |
|---|---|
| Platform capacity (SWL) | 500 lb |
| Max. wind speed | 28 mph |
| Max. drive speed (stowed) | 2.5 mph |
| Max. drive speed (elevated) | 0.4 mph |
| Raise/lower time | 12.5/10.5 sec |
| Gradeability | 25% |
| Max. operating slope (side to side) | 2º |
| Max. operating slope (front to back) | 2º |
| Inside turning radius | 0 in |
| Outside turning radius | 55.5 in |
Dimensions 9 specs
| Max. platform height (A) | 12 ft |
|---|---|
| Platform size (stowed) | 27 in x 39 in |
| Platform size (extended) (E) | 27 in x 59 in |
| Extension deck length | 20 in |
| Overall length (D) | 4 ft 6 in |
| Overall width (B) | 2 ft 6 in |
| Stowed height (C) | 5 ft 6 in |
| Ground clearance | 3 in |
| Max. drive height | 12 ft |
Weight 1 spec
| Weight | 2,240 lb |
|---|
