Telehandler · Bobcat
Bobcat T40140 Specs
Quick-reference specifications for the Bobcat T40140 telehandler, taken from the manufacturer’s spec sheet.
- Maximum Lift Capacity
- 4100 kg
- Maximum Lift Height (on tyres / on stabilizers)
- 13300 / 13600 mm
- Maximum Forward Reach (on tyres / on stabilizers)
- 9800 / 9800 mm
Performance 11 specs
| Maximum Lift Capacity | 4100 kg |
|---|---|
| Maximum Forward Reach (on tyres / on stabilizers) | 9800 / 9800 mm |
| Lift Capacity at Full Height (on tyres / on stabilizers) | 2500 / 4000 kg |
| Lift Capacity at Full Reach (on tyres / on stabilizers) | 500 / 1300 kg |
| Tilt Crowding Force | 12300 daN |
| Standard Tyres | Basic Option Tyres 400/80-24 in |
| Low Speed (forward / reverse) | 8.5 km/h |
| High Speed (forward / reverse) | 30 km/h |
| Main Drive | Hydrostatic motor |
| Service Brake | Oil immersed discs |
| Parking and Emergency Brake | Negative brake with hydraulic command |
Dimensions 1 spec
| Maximum Lift Height (on tyres / on stabilizers) | 13300 / 13600 mm |
|---|
Weight 1 spec
| Weight (unladen) | 10290 kg |
|---|
Power / Engine 8 specs
| Stage | IIIA |
|---|---|
| Make / Model | PERKINS / 1104D-44TA |
| Fuel / Cooling | DIESEL / Water |
| Rated Power (ISO 14396) at 2300 RPM | 100 HP (74.5 kW) |
| Maximum Torque at 1600 RPM | 410 Nm |
| Number of Cylinders | 4 |
| Displacement | 4.4 l |
| Transmission | Hydrostatic with electronic regulation |
Hydraulics / Fluids 3 specs
| Pump Type | Gear pump with LS valve |
|---|---|
| Combined Pump Capacity | 100 l/min |
| Working Pressure | 255 bar |
