Telehandler · Bobcat
Bobcat TL38.70HF Specs
Quick-reference specifications for the Bobcat TL38.70HF telehandler, taken from the manufacturer’s spec sheet.
- Rated capacity
- 3800 kg
- Capacity (at max. height on tyres)
- 3500 kg
Performance 15 specs
| Rated capacity | 3800 kg |
|---|---|
| Capacity (at max. height on tyres) | 3500 kg |
| Capacity at max. reach | 1500 kg |
| Tilt Breakout force | 6200 daN |
| Drawbar pull | 8000 daN |
| Max. reach | 4002.0 mm |
| Boom raising | 4.9 s |
| Boom lowering | 4.3 s |
| Boom extension | 4.8 s |
| Boom retraction | 4.9 s |
| Rated speed | 2400.0 RPM |
| Standard Tyres | 405/70-20 16PR TM R4 |
| Operator noise level (LpA) (EN 12053) | 73 dB (A) |
| Sound pressure level at the operator station 2014 /1322 | 73 dB (A) |
| Whole body vibration (EN 13059) | 1.40 ms |
Dimensions 1 spec
| Lifting height | 6889.0 mm |
|---|
Weight 2 specs
| Unladen weight (20″ tyres) | 7190 kg |
|---|---|
| Unladen weight (24″ tyres) | 7330 kg |
Power / Engine 5 specs
| Maximum torque at 1400 rpm | 500.0 Nm |
|---|---|
| Number of cylinders | 4.0 |
| Displacement | 3.41 L |
| LS piston pump with electric displacement limiter | 190.00 L/min |
| Level of acoustic power (LwA) | 107 dB (A) |
Hydraulics / Fluids 5 specs
| Relief valve pressure setting | 255.00 bar |
|---|---|
| Fuel tank | 138.00 L |
| Adblue ® tank | 28.80 L |
| Hydraulic tank | 59.00 L |
| Hydraulic system | 126.00 L |
