Telehandler · Bobcat
Bobcat TL25.60 AGRI Specs
Quick-reference specifications for the Bobcat TL25.60 AGRI telehandler, from the manufacturer’s spec sheet and published specifications.
- Rated Capacity
- 5,511 lb2,500 kg
- Maximum Lift Height
- 19.4 ft5.9 m
- Maximum Forward Reach
- 10.8 ft3.3 m
Performance 6 specs
| Rated Capacity | 5,511 lb (2,500 kg) |
|---|---|
| Maximum Lift Height | 19.4 ft (5.9 m) |
| Maximum Forward Reach | 10.8 ft (3.3 m) |
| Load at Maximum Lift Height | 1.8 tonnes (3,968 lb) |
| Load at Maximum Reach | 1,764 lb (800 kg) |
| Turning Radius | 10.6 ft (3.235 m) |
Dimensions 5 specs
| Width | 72.1 in (1.832 m) |
|---|---|
| Height (standard 12-16.5 tyres) | 75.4 in (1.93 m) |
| Height (20 in tyres) | 77.4 in (1.97 m) |
| Height (20 in tyres with beacon) | 83.5 in (2.12 m) |
| Ground Clearance (20 in tyres) | 11.4 in (0.29 m) |
Weight 1 spec
| Unladen Weight | 9,494 lb (4,308 kg) |
|---|
Power / Engine 2 specs
| Engine Displacement | 2.39 litres |
|---|---|
| Rated Power (ISO 14396) | 75 HP (55 kW) |
Hydraulics / Fluids 1 spec
| Front Auxiliary Hydraulic Flow | 80 l/min (21.1 gal/min) |
|---|
