- Caterpillar 2P3000
Forklift · Caterpillar
Caterpillar 2P3000 Specs
Quick-reference specifications for the Caterpillar 2P3000 forklift, taken from the manufacturer’s spec sheet.
- Capacity at rated load center
- 3,000 lb1,500 kg
- Gradeability loaded at 1 mph (1.6 km)
- 47.4 %
Performance 10 specs
| Capacity at rated load center | 3,000 lb (1,500 kg) |
|---|---|
| Capacity at load center – distance | 24 in (500 mm) |
| Tilt forward / backward | 6° / 10° |
| Minimum outside turning radius | 76.8 in (1,950 mm) |
| Speeds travel loaded / empty | 11.0 / 12.0 mph (17.5 / 19.0 km/h) |
| Speeds lift speed loaded / empty | 120 / 125 fpm (620 / 630 mm/s) |
| Speeds lowering speed loaded / empty | 98 / 98 fpm (500 / 500 mm/s) |
| Gradeability loaded at 1 mph (1.6 km) | 47.4 % |
| Gradeability maximum loaded / empty | 38.8 / 18.2 % |
| Axle load with rated load front / rear (est.) | 7,710 / 940 lb (3,620 / 440 kg) |
Dimensions 11 specs
| Tire type | pneumatic |
|---|---|
| Lift with standard maximum fork height | 130 in (3,300 mm) |
| Two-stage mast free fork height | 4.5 in (115 mm) |
| Forks thickness x length x width | 1.4 x 4 x 42 in (35 x 100 x 1,070 mm) |
| Fork spacing out-to-out minimum / maximum | 7.9 / 36.2 in (200 / 920 mm) |
| Overall dimensions length to fork face | 89 in (2,260 mm) |
| Overall dimensions width with standard tires | 42 in (1,070 mm) |
| Overall dimensions height with lowered mast | 84.5 in (2,150 mm) |
| Overall dimensions height seat height | 43.5 in (1,105 mm) |
| Overall dimensions height to top of overhead guard | 82.5 in (2,100 mm) |
| Overall dimensions height with extended mast | 180 in (4,570 mm) |
Weight 1 spec
| Axle load without load front / rear (est.) | 2,490 / 3,160 lb (1,130 / 1,430 kg) |
|---|
