Forklift · Caterpillar
Caterpillar FG25N Specs
Quick-reference specifications for the Caterpillar FG25N forklift, compiled from published specifications.
- Operating Weight
- 7,980.8 lb3,620 kg
Performance 7 specs
| Load Capacity | 5,000 lb (2,268 kg) |
|---|---|
| Max Speed | 11.5 mph |
| Lift Speed | 0.12 ft/min |
| Lower Speed | 98.43 ft/min |
| Turning Radius | 7.32 ft (2.23 m) |
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
Dimensions 8 specs
| Length to Fork Face | 8.37 ft |
|---|---|
| Overall Width | 3.78 ft |
| Overall Height – Mast Lowered | 7.04 ft (2.14 m) |
| Height to Top of Overhead Guard | 6.91 ft |
| Max Fork Height | 10.96 ft |
| Wheelbase | 5.25 ft (1.4 m) |
| Ground Clearance | 4.61 in (117 mm) |
| Load Center | 19.69 in (500 mm) |
Weight 1 spec
| Operating Weight | 7,980.8 lb (3,620 kg) |
|---|
Power / Engine 5 specs
| Engine Model | GK21E |
|---|---|
| Number of Cylinders | 4 |
| Displacement | 128.2 cu in (2.1 L) |
| Power | 53 hp |
| Power Measured @ | 2,700 rpm |
