Caterpillar P9000 Specs
Quick-reference specifications for the Caterpillar P9000 forklift, taken from the manufacturer’s spec sheet.
- Capacity at rated load center
- 9,000 lb4,000 kg
- Gradeability loaded at 1 mph (1.6 km)
- 28.9 %
Performance 11 specs
| Capacity at rated load center | 9,000 lb (4,000 kg) |
|---|---|
| Tilt forward / backward | 6° / 10° |
| Minimum outside turning radius | 107.0 in (2,730 mm) |
| Speeds travel speed loaded / empty | 13.5 / 14.0 fpm (22.0 / 22.5 km/h) |
| Speeds lift speed loaded / empty | 104 / 110 fpm (0.53 / 0.56 m/s) |
| Speeds lowering speed loaded / empty | 94 / 75 fpm (0.48 / 0.38 m/s) |
| Gradeability loaded at 1 mph (1.6 km) | 28.9 % |
| Gradeability maximum loaded | 40.2 % |
| Axle load with rated load front / rear | 20,400 / 2,400 lb (9,110 / 1,160 kg) |
| Brakes service | foot, hydraulic |
| Brakes parking | hand, mechanical |
Dimensions 20 specs
| Tire type | pneumatic |
|---|---|
| Lift with standard maximum fork height (top of fork) | 132 in (3,300 mm) |
| Two-stage mast free fork height | 5.9 in (150 mm) |
| Fork spacing out-to-out minimum / maximum | 12.6 / 46.6 in (320 / 1,184 mm) |
| Overall dimensions length to fork face | 123 in (3,130 mm) |
| Overall dimensions width with standard tires | 57.5 in (1,460 mm) |
| Overall dimensions width with optional duals | 77.5 in (1,965 mm) |
| Overall dimensions height with lowered mast | 91.5 in (2,320 mm) |
| Overall dimensions height seat height | 42.6 in (1,082 mm) |
| Overall dimensions height to top of overhead guard | 90.5 in (2,296 mm) |
| Overall dimensions height with extended mast | 180.0 in (4,570 mm) |
| Tire size front, standard | 300x15x20PR |
| Tire size front, optional duals | 8.25x15x14PR |
| Tire size rear | 7.00x12x12PR |
| Wheelbase | 78.5 in (2,000 mm) |
| Tread width front, standard tires | 46.5 in (1,175 mm) |
| Tread width front, optional duals | 57.0 in (1,445 mm) |
| Tread width rear tires | 46.5 in (1,180 mm) |
| Ground clearance at lowest point at mast | 5.9 in (150 mm) |
| Ground clearance at center of wheelbase | 8.9 in (227 mm) |
Weight 1 spec
| Axle load without load front / rear | 6,050 / 7,750 lb (2,750 / 3,520 kg) |
|---|
Power / Engine 6 specs
| Engine model | Nissan TB45K |
|---|---|
| Engine continuous output S.A.E. gross | 97 HP (72 kW) |
| Engine maximum torque S.A.E. gross | 207 lb-ft (280 N-m) |
| Engine cylinder / displacement | 6 / 275 cu in (6 / 4.5 L) |
| Transmission type | powershift |
| Battery volts | 12 |
