Doosan D15S-5 Specs
Quick-reference specifications for the Doosan D15S-5 forklift, taken from the manufacturer’s spec sheet.
- Max. gradeability Loaded at 1.0 mph (1.6km/h)
- 32 %
Performance 15 specs
| Load Capacity at rated load center | 1,500 kg |
|---|---|
| Load Center | 500 mm |
| Free Lift | 135 mm |
| Fork Spacing(Min x Max) | 240×905 mm |
| Tilt of Mast Forward/Backward | 6 / 8 deg |
| Turning Radius Minimum outside | 1,977 mm |
| Travel Speed Loaded/Unloaded | 19 / 20 km/h |
| Lifting Speed Loaded/Unloaded | 600 / 630 mm/s |
| Lowering Speed Loaded/Unloaded | 500 / 450 mm/s |
| Max. drawbar pull Loaded at 1.0 mph (1.6km/h) | 1,400 kg |
| Max. gradeability Loaded at 1.0 mph (1.6km/h) | 32 % |
| Tires Size, Front | 6.50×10-12 |
| Tires Size, Rear | 5.00×8-10 |
| Brakes Service | Foot / Hyd |
| Brakes Parking | Hand / Mech |
Dimensions 13 specs
| Tire type | P |
|---|---|
| Max. Fork Height with STD 2-stage mast | 3,300 mm |
| Forks Length x Width x Thickness | 900x100x35 mm |
| Length to Fork Face | 2,170 mm |
| Overall Width | 1,070 mm |
| Mast Lowered Height | 2,185 mm |
| Mast Extended Height | 4,355 mm |
| Overhead Guard Height | 2,170 mm |
| Seat Height | 1,005 mm |
| Load Moment Center | 394 mm |
| Tread Width Front/Rear | 890 / 910 mm |
| Ground Clearance Loaded at the lowest point | 120 mm |
| Ground Clearance Loaded at center of wheelbase | 150 mm |
Weight 3 specs
| Total Service Weight, Unloaded | 2,880 kg |
|---|---|
| Axle Load Loaded, Front/Rear | 3,800 / 580 kg |
| Axle Load Unloaded, Front/Rear | 1,340 / 1,560 kg |
Power / Engine 5 specs
| Power type | Diesel |
|---|---|
| Battery Voltage/Ampere | 12 / 60 V/AH |
| Rated Power(DIN) | 45.8 / 2,400 HP/rpm (34.2 / 2,400 kW/rpm) |
| Cylinders/Displacements | 4 / 2,434 cc |
| Transmission Type | powershift |
Hydraulics / Fluids 2 specs
| Hydraulic Pressure System | 176 bar |
|---|---|
| Hydraulic Pressure Attachment | 176 bar |
