Doosan D20S-9 Specs

Quick-reference specifications for the Doosan D20S-9 forklift, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Gradeability. loaded/unloaded (@ 1.6km/h): 33.6/55.2 %

Performance 13 specs

Load Capacity	2,000 kg
Tyres: pneumatic (P). solid (E)	P/E
Tilt of Mast/Fork carriage Forward/Backward	6/10 °
External Turning Radius	2,230 mm
Travel Speed. loaded/unloaded	20/21 km/h
Lift Speed. loaded/unloaded	0.61/0.65 m/s
Lowering Speed. loaded/unloaded	0.51/0.45 m/s
Drawbar pull. loaded/unloaded (@ 1.6km/h)	17,780/17,500 N
Max. Drawbar pull. loaded/unloaded	19,860/19,400 N
Gradeability. loaded/unloaded (@ 1.6km/h)	33.6/55.2 %
Max. Gradeability. loaded/unloaded	38.1/63.5 %
Service Brake	foot/hydraulic
Rated Speed	2,200 min-1

Dimensions 18 specs

Load Center	500 mm
Load Distance: Center of Drive axle to fork	480 mm
Wheelbase	1,700 mm
Tyre size. Front	7.00X15-12
Tyre size. Rear	6.50X10-10
Height. Mast lowered	2,190 mm
Free Lift	147 mm
Maximum fork height	3,230 mm
Height. Mast Extended	4,490 mm
Height of Overhead Guard	2,183 mm
Height of Seat	1,026 mm
Overall Length	3,624 mm
Length to Forkface	2,574 mm
Fork Dimensions	40X100X1,050 mm
Fork carriage ISO 2328. class/type	A.B
Fork carriage width	1,103 mm
Aisle width for pallets 1.000 x 1.200 crossways	3,910 mm
Aisle width for pallets 800 x 1.200 lengthways	4,110 mm

Weight 3 specs

Service weight	3,830 kg
Axle Loading. loaded. front/rear	4,977/853 kg
Axle Loading. unloaded. front/rear	1,825/2,005 kg

Power / Engine 6 specs

Engine Manufacturer/type	DI/DM02VA
Engine power according to DIN ISO1585	45.6 kW
Torque at 1/min	300/1,200-1,400 Nm/rpm
Number of Cylinders/Displacement	4/2,392 -/cm3
Fuel Consumption according to VDI Cycle	2.8 l/h
Battery Voltage/normal capacity	12/85 V/Ah

Hydraulics / Fluids 3 specs

Operating pressure for attachments	156 bar
Oil flow for attachments	76.5 l/min
Fuel Tank Capacity	58 l
