Doosan D160S-5 Specs

Quick-reference specifications for the Doosan D160S-5 forklift, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Max. gradeability Loaded at 1.0 mph(1.6 km/h): 28.5 %

Performance 15 specs

Load Capacity at rated load centre	16,000 kg
Load Centre	600 mm
Free Lift	0 mm
Fork Spacing(Min x Max)	470 x 2,290 mm
Tilt of Mast Forward/Backward	15 / 12 deg
Turning Radius Minimum outside	4,400 mm
Travel Speed Loaded/Unloaded	29.0 / 33.0 km/h
Lifting Speed Loaded/Unloaded	410 / 450 mm/s
Lowering Speed Loaded/Unloaded	430 / 410 mm/s
Max. drawbar pull Loaded at 1.0 mph(1.6 km/h)	10,400 kg
Max. gradeability Loaded at 1.0 mph(1.6 km/h)	28.5 %
Tyres Size , Front	12.00 x 20 – 18PR
Tyres Size , Rear	12.00 x 20 – 18PR
Brakes Service	Foot / Air
Brakes Parking	Hand / Air

Dimensions 13 specs

Tire Type	P
Max. Fork Height with STD 2-stage mast	3,000 mm
Forks Length x Width x Thickness	1,350 x 200 x 85 mm
Length to Fork Face	4,715 mm
Overall Width	2,490 mm
Overall Dimensions Mast Lowered Height	3,170 mm
Overall Dimensions Mast Extended Height	4,670 mm
Overhead Guard Height	2,928 mm
Seat Height	1,820 mm
Load Moment Centre	815 mm
Tread Width Front / Rear	1,825 / 1,910 mm
Ground Clearance Loaded at the lowest point	270 mm
Ground Clearance Loaded at centre of wheelbase	370 mm

Weight 3 specs

Total Service Weight , Unloaded	18,900 kg
Axle Load Loaded, Front / Rear	31,870 / 3,030 kg
Axle Load Unloaded, Front / Rear	8,680 / 10,220 kg

Power / Engine 4 specs

Power Type	Diesel
Maximum Torque – DL06	67 kgm/1,400 rpm
Maximum Torque – DE08TS	63 kgm/1,400 rpm
Transmission Type	Full Autoshift

Hydraulics / Fluids 2 specs

Hydraulic Pressure System	210 bar
Hydraulic Pressure Attachment	140 bar
