Forklift · Doosan
Doosan G15S-5 Specs
Quick-reference specifications for the Doosan G15S-5 forklift, taken from the manufacturer’s spec sheet.
- Capacity at rated load center
- 1,500 kg
- Gradeability at 1.6km/hr, loaded/unloaded
- 35.5 %
Performance 8 specs
| Capacity at rated load center | 1,500 kg |
|---|---|
| Tilt of mast – forward/backward | 6 / 8 deg |
| Outside turning radius | 1,977 mm |
| Speed – travel, loaded/unloaded | 18 / 19 km/h |
| Speed – lift, loaded/unloaded | 600 / 650 mm/s |
| Speed – lowering, loaded/unloaded | 500 / 450 mm/s |
| Drawbar pull at 1.6km/hr, loaded/unloaded | 1,440 kg |
| Gradeability at 1.6km/hr, loaded/unloaded | 35.5 % |
Dimensions 17 specs
| Load center distance | 500 mm |
|---|---|
| Tires | P |
| Lift with STD two-stage mast – free lift | 135 mm |
| Forks – thickness x width x length | 900 x 100 x 35 mm |
| Forks – fork spacing (minimum x maximum) | 240 x 905 mm |
| Overall dimensions – length to fork face | 2,170 mm |
| Overall dimensions – width | 1,070 mm |
| Overall dimensions – mast lowered height | 2,185 mm |
| Overall dimensions – mast extended height | 4,355 mm |
| Overall dimensions – overhead guard height | 2,170 mm |
| Overall dimensions – seat height | 1,005 mm |
| Tires – front size | 6.50×10-12 |
| Tires – rear size | 5.00×8-10 |
| Ground Clearance – loaded, the lowest point | 120 mm |
| Ground Clearance – loaded, center of wheelbase | 150 mm |
| Service brake | foot / hydr |
| Parking brake | hand / mech |
Weight 3 specs
| Total weight, unloaded | 2,800 kg |
|---|---|
| Axle load with load, front/rear | 3,775 / 525 kg |
| Axle load with unload, front/rear | 1,320 / 1,485 kg |
Power / Engine 6 specs
| Power type | LPG |
|---|---|
| Battery – voltage/capacity | 12 / 45 V/AH |
| Engine – manufacturer/model | HMC / G424I (E) |
| Engine – rated output / rpm | 33.9 / 2,450 kw |
| Engine – cycle/cylinders/displacement | 4 / 2,359 cc |
| Transmission – type | powershift |
Hydraulics / Fluids 1 spec
| Operating pressure – system/attachment | 176 / 176 bar |
|---|
