Doosan D30NXP Specs
Quick-reference specifications for the Doosan D30NXP forklift, from the manufacturer’s spec sheet and published specifications.
- Gradeability
- 25%
Performance 1 spec
| Gradeability | 25% |
|---|
Dimensions 8 specs
| Overall Length to Fork Face | 2,665 mm |
|---|---|
| Total Width | 50.8 in (1,290 mm) |
| Lifting Height | 15.5 ft (4,710 mm) |
| Construction Height | 7.3 ft (2,225 mm) |
| Turning Radius | 7.9 ft (2,415 mm) |
| Free Lift | 2.9 ft (890 mm) |
| Fork Length | 3.9 ft (1,200 mm) |
| Fork Carriage Width | 1,110 mm |
Weight 2 specs
| Load Capacity | 6,614 lb (3,000 kg) |
|---|---|
| Load Center | 20 in (500 mm) |
