Forklift · Doosan
Doosan G25E Specs
Quick-reference specifications for the Doosan G25E forklift, from the manufacturer’s spec sheet and published specifications.
Performance 3 specs
| HP/rpm | 59 / 2,300 |
|---|---|
| Load Capacity | 5,000 lb (2,268 kg) |
| Max Speed | 12.4 mph (20 kph) |
Dimensions 4 specs
| Length to Fork Face | 8.44 ft (2.57 m) |
|---|---|
| Overall Width | 3.85 ft (1.17 m) |
| Height to Top of Overhead Guard | 7.16 ft (2.18 m) |
| Turning Radius | 7.44 ft (2.27 m) |
Power / Engine 2 specs
| Power | 51.3 hp (38 kW) |
|---|---|
| Displacement | 146.5 cu in (2,401 cu cm) |
