Doosan G30P-7 Specs

Quick-reference specifications for the Doosan G30P-7 forklift, taken from the manufacturer’s spec sheet.

Performance 14 specs

Load Capacity Q	3,000 kg
Tyres: pneumatic (P). solid (E)	P/E
Tilt of Mast/Fork carriage Forward/Backward α/β	6/10 °
External Turning Radius Wa	2,365 mm
Internal Turning Radius b	761 mm
Travel Speed. loaded/unloaded	18/18.5 km/h
Lift Speed. loaded/unloaded	0.56/0.61 m/s
Lowering Speed. loaded/unloaded	0.51/0.46 m/s
Drawbar pull. loaded/unloaded (@ 1.6km/h)	16,220/16,120 N
Max. Drawbar pull. loaded/unloaded	18,970/18,580 N
Gradeability. loaded/unloaded (@ 1.6km/h)	23.0/40.5 %
Max. Gradeability. loaded/unloaded	27.0/48.0 %
Service Brake	foot/hydraulic
Rated Speed	2,600 min-1

Load Center c	500 mm
Load Distance: Center of Drive axle to fork x	485 mm
Wheelbase y	1,700 mm
Tyre size. Front	28x9x15-12
Tyre size. Rear	6.50×10-10
Height. Mast lowered h	2,165 mm
Free Lift h	152 mm
Lift Height h	3,230 mm
Height. Mast Extended h	4,490 mm
Height of Overhead Guard (Cabin) h	2,183 mm
Height of Seat h	1,026 mm
Overall Length l	3,744 mm
Length to Forkface l	2,700 mm
Overall Width b1/b	1,197 mm
Fork Dimensions s/e/l	40x100x1,050 mm
Fork carriage ISO 2328. class/type A.B	III/A
Fork carriage width b	1,115 mm
Ground Clearance. loaded. below mast m	115 mm
Ground Clearance. center of wheelbase m	143 mm
Aisle width for pallets 1.000 x 1.200 crossways Ast	4,050 mm
Aisle width for pallets 800 x 1.200 lengthways Ast	4,250 mm

Service weight	4,430 kg
Axle Loading. loaded. front/rear	6,580/850 kg
Axle Loading. unloaded. front/rear	1,830/2,600 kg

Engine Manufacturer/type	MITSU/G424P (E)
Engine power according to DIN ISO1585	48,9 kW
Torque at 1/min	183/2,000 Nm/rpm
Number of Cylinders/Displacement	4/2,351 -/cm3
Battery Voltage/normal capacity	12/65 V/Ah

Operating pressure for attachments	156 bar
Oil flow for attachments	60 l/min
Fuel Tank Capacity	51 l
