Doosan G35C-7 Specs

Quick-reference specifications for the Doosan G35C-7 forklift, taken from the manufacturer’s spec sheet.

Performance 14 specs

Load Capacity Q	3,500 kg
Tyres: pneumatic (P), solid (E)	P/E
Tilt of Mast/Fork carriage Forward/Backward α/β	6/10 °
External Turning Radius Wa	2,420 mm
Internal Turning Radius b	761 mm
Travel Speed, loaded/unloaded	18.5/19 km/h
Lift Speed, loaded/unloaded	0.55/0.61 m/s
Lowering Speed, loaded/unloaded	0.51/0.46 m/s
Drawbar pull, loaded/unloaded (@ 1.6km/h)	15,630/15,550 N
Max. Drawbar pull, loaded/unloaded	18,250/17,850 N
Gradeability, loaded/unloaded (@ 1.6km/h)	20.0/35.5 %
Max. Gradeability, loaded/unloaded	23.0/41.5 %
Service Brake	foot/hydraulic
Rated Speed	2,600 min-1

Load Center c	500 mm
Load Distance: Center of Drive axle to fork x	495 mm
Wheelbase y	1,700 mm
Tyre size, Front	250×15-18
Tyre size, Rear	6.50×10-12
Height, Mast lowered h	2,165 mm
Free Lift h	152 mm
Lift Height h	3,230 mm
Height, Mast Extended h	4,260 mm
Height of Overhead Guard (Cabin) h	2,183 mm
Height of Seat h	1,026 mm
Overall Length l	3,809 mm
Length to Forkface l	2,765 mm
Overall Width b1/b	1,255 mm
Fork Dimensions s/e/l	40x100x1,050 mm
Fork carriage ISO 2328, class/type	III/A
Fork carriage width b	1,115 mm
Ground Clearance, loaded, below mast m	115 mm
Ground Clearance, center of wheelbase m	143 mm
Aisle width for pallets 1,000 x 1,200 crossways Ast	4,115 mm
Aisle width for pallets 800 x 1,200 lengthways Ast	4,315 mm

Service weight	4,800 kg
Axle Loading, loaded, front/rear	7,340/960 kg
Axle Loading, unloaded, front/rear	1,800/3,000 kg

Engine Manufacturer/type	MITSU/G424P (E)
Engine power according to DIN ISO1585	48.9 kW
Torque at 1/min	183/2,000 Nm/rpm
Number of Cylinders/Displacement	4/2,351 -/cm3
Battery Voltage/normal capacity	12/65 V/Ah

Operating pressure for attachments	156 bar
Oil flow for attachments	60 l/min
Fuel Tank Capacity	51 l
