Doosan G35S-5 Specs
Quick-reference specifications for the Doosan G35S-5 forklift, taken from the manufacturer’s spec sheet.
- Max. gradeability Loaded at 1.0 mph (1.7km / h)
- 36 %
Performance 12 specs
| Load Capacity at rated load center | 3,500 kg |
|---|---|
| Load Center | 600 mm |
| Free Lift | 160 mm |
| Fork Spacing(Min x Max) | 310 x 1,182 mm |
| Tilt of Mast Forward / Backward | 8 / 10 deg |
| Turning Radius Minimum outside | 2,770 mm |
| Travel Speed Loaded / Unloaded | 20 / 21 km/h |
| Lifting Speed Loaded / Unloaded | 500 / 540 mm/s |
| Lowering Speed Loaded / Unloaded | 480 / 450 mm/s |
| Max. drawbar pull Loaded at 1.0 mph (1.6km / h) | 3,355 kg |
| Max. gradeability Loaded at 1.0 mph (1.7km / h) | 36 % |
| Brakes Service | shoe / disc |
Dimensions 13 specs
| Tire type | P |
|---|---|
| Max. Fork Height with STD 2-stage mast | 3,000 mm |
| Forks Length x Width x Thickness | 1,050x150x50 mm |
| Length to Fork Face | 3,100 mm |
| Overall Width | 1,372 mm |
| Overall Dimensions Mast Lowered Height | 2,225 mm |
| Mast Extended Height | 4,265 mm |
| Overhead Guard Height | 2,225 mm |
| Seat Height | 1,248 mm |
| Load Moment Center | 561 mm |
| Tread Width Front / Rear | 1,138 / 1,115 mm |
| Ground Clearance Loaded at the lowest point | 160 mm |
| Loaded at center of wheelbase | 205 mm |
Weight 4 specs
| Total Service Weight, Unloaded | 5,790 kg |
|---|---|
| Axle Load Loaded, Front / Rear | 8,215 / 1,075 kg |
| Unloaded, Front / Rear | 2,685 / 3,105 kg |
| Tires Size, Front | 8.25×15-14 |
Power / Engine 6 specs
| Power type | LPG |
|---|---|
| Battery Voltage / Ampere | 12 / 75 V/AH |
| Engine Rated Power(DIN) | 93 / 2,450 HP/rpm (69 / 2,450 kW/rpm) |
| Maximum Torque | 31/ 1,400 kgm/rpm |
| Cylinders / Displacements | 6 / 4,294 CC |
| Transmission Type | powershift |
Hydraulics / Fluids 1 spec
| Hydraulic Pressure System | 190 bar |
|---|
