Aerial Lift · Haulotte
Haulotte 6543A Specs
Quick-reference specifications for the Haulotte 6543A aerial lift, taken from the manufacturer’s spec sheet.
- Lift capacity
- 500 lb
- Platform height
- 65 ft
- Working height
- 71 ft
Performance 8 specs
| Working height | 71 ft |
|---|---|
| Horizontal outreach (from centerline) | 43 ft |
| Horizontal outreach (from edge of footpad) | 37 ft |
| Lift capacity | 500 lb |
| Jib – Vertical Motion | 150° (+70 / – 80) |
| Turntable rotation | 350° non-continuous |
| Leveling capability | 12.5 ° |
| Tow speed rating | 65 mph |
Dimensions 7 specs
| Platform height | 65 ft |
|---|---|
| Up and over height | 24 ft 2 in |
| Jib – length | 4 ft 3 in |
| Length – stowed | 24 ft |
| Width stowed | 5 ft 11 in |
| Height stowed | 7 ft |
| Platform size | 4 ft 1 in x 2 ft 9 in |
Weight 2 specs
| Tongue weight (no options) | 550 lb |
|---|---|
| Weight (no options) | 7,700 lb |
Power / Engine 1 spec
| Power source | 4 x 6 V 245 amp-hr |
|---|
