Aerial Lift · Haulotte

Haulotte COMPACT 3368RT Specs

Quick-reference specifications for the Haulotte COMPACT 3368RT aerial lift, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Lift capacity: 1000 lb
Platform height: 33 ft 4 in
Working height: 39 ft 4 in
Weight: 8,959 lb

Performance 7 specs

Working height	39 ft 4 in
Lift capacity	1000 lb
Drive speed	0.5 – 3.4 mph
Turning radius – outside	11 ft 6 in
Lift / lower speed	40 s / 51s
Gradeability	40 %
Tires	26×12-16.5

Dimensions 12 specs

Platform height	33 ft 4 in
Length	10 ft 5 in
Width	5 ft 11 in
Height – stowed	8 ft 4 in
Storage height	5 ft 2 in
Platform length	8 ft 3 in
Extended platform length	12 ft 2 in
Platform extension length	3 ft 11 in
Platform width	5 ft 1 in
Wheelbase	6 ft 2 in
Ground clearance	11 in
Number of extensions	1

Weight 1 spec

Weight	8,959 lb

Power / Engine 1 spec

Engine	24.8 hp (18.5 kW -)

Hydraulics / Fluids 1 spec

Hydraulic tank capacity	20 gal

Haulotte COMPACT 3368RT spec sheet (PDF)
