Aerial Lift · Haulotte
Haulotte H12SXL Specs
Quick-reference specifications for the Haulotte H12SXL aerial lift, from the manufacturer’s spec sheet and published specifications.
- Max Platform Capacity
- 1,545 lb700 kg
- Max Working Height
- 39 ft 4 in12 m
- Operating Weight
- 12,566 lb5,700 kg
- Gradeability
- 40%
Performance 7 specs
| Max Working Height | 39 ft 4 in (12 m) |
|---|---|
| Max Platform Height | 32 ft 10 in (10 m) |
| Max Speed | 3.8 mph (6 km/h) |
| Gradeability | 40% |
| Lift Time | 43 sec |
| Lower Time | 65 sec |
| Tire Size | 10 x 16.5 |
Dimensions 6 specs
| Overall Length | 17 ft 4 in (5.3 m) |
|---|---|
| Overall Width | 7 ft 5 in (2.25 m) |
| Stowed Height | 8 ft 5 in (2.57 m) |
| Turning Radius | 20 ft 4 in (6.2 m) |
| Platform Length | 23 ft 11 in (7.3 m) |
| Platform Width | 6 ft 2 in (1.9 m) |
Weight 2 specs
| Operating Weight | 12,566 lb (5,700 kg) |
|---|---|
| Max Platform Capacity | 1,545 lb (700 kg) |
Power / Engine 3 specs
| Engine Type | KDI 2504 |
|---|---|
| Gross Power | 32.2 hp (24 kW) |
| Fuel Capacity | 17.2 gal (65 L) |
Hydraulics / Fluids 1 spec
| Hydraulic Fluid Capacity | 26.5 gal (100 L) |
|---|
