Hyster H2.0FT Specs
Quick-reference specifications for the Hyster H2.0FT forklift, from the manufacturer’s spec sheet and published specifications.
- Operating Weight (Diesel variant)
- 7,262 lb3,293 kg
Performance 5 specs
| Load distance, centre of drive axle to fork | x |
|---|---|
| Rated Load Capacity | 4,409 lb (2,000 kg) |
| Max Speed | 13 mph (20.9 km/h) |
| Turning Radius | 6.42-7.06 ft (1.96-2.15 m) |
| Max Fork Height | 10.67-10.8 ft (3.25-3.29 m) |
Dimensions 12 specs
| Tyre size, front | 7.00 X 12 – 12 |
|---|---|
| Ground clearance, laden, below mast | m1 |
| Ground clearance, centre of wheelbase | m2 |
| Overall Length to Fork Face | 7.34-8.16 ft (2.24-2.49 m) |
| Overall Width | 3.52-3.8 ft (1.07-1.16 m) |
| Overall Height (Mast Lowered) | 7.06-7.14 ft (2.15-2.17 m) |
| Wheelbase | 4.55-5.33 ft (1.39-1.62 m) |
| Ground Clearance | 4.34-6.3 in (110-160 mm) |
| Height to Top of Overhead Guard | 7.06-7.09 ft (2.15-2.16 m) |
| Load Center Distance | 19.69 in (500 mm) |
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 5 degrees |
Weight 3 specs
| Operating Weight (Diesel variant) | 7,262 lb (3,293 kg) |
|---|---|
| Operating Weight (LPG variant) | 7,262 lb (3,293 kg) |
| Operating Weight (DM+2 variants) | 8,130.7 lb (3,688 kg) |
Power / Engine 7 specs
| Fuel consumtion according to VDI cycle | l/h |
|---|---|
| Engine Type (standard Diesel) | Yanmar 4TNE92 |
| Power (Diesel base) | 29.1 hp (21.7 kW) |
| Power (LPG base) | 29.8 hp (22.2 kW) |
| Power (DM+2 Diesel) | 65.1 hp (48.6 kW) |
| Power Measured @ | 2,400-2,600 rpm |
| Number of Cylinders | 4 |
