Forklift · Hyster
Hyster H2.0FTS Specs
Quick-reference specifications for the Hyster H2.0FTS forklift, from the manufacturer’s spec sheet and published specifications.
Performance 12 specs
| Electronic Powershift | 1-speed |
|---|---|
| Load distance, centre of drive axle to fork | x |
| Load Capacity | 4,409 lb (2,000 kg) |
| Load Centre Distance | 19.7 in (500 mm) |
| Max Travel Speed with Load | 20.5 km/h |
| Max Travel Speed without Load | 20.9 km/h |
| Hoisting Speed with Load (Diesel) | 0.62 m/s |
| Hoisting Speed without Load (Diesel) | 0.72 m/s |
| Lowering Speed with Load (Diesel) | 0.51 m/s |
| Turning Radius | 6.51 ft (1.985 m) |
| Mast Tilt Forward | 6° |
| Mast Tilt Backward | 5° |
Dimensions 7 specs
| Ground clearance, laden, below mast | m1 |
|---|---|
| Ground clearance, centre of wheelbase | m2 |
| Overall Length to Fork Face | 7.34 ft (2,236 mm) |
| Overall Width | 42.0-43.6 in (1,068-1,108 mm) |
| Construction Height (Mast Lowered) | 7.05 ft (2,149 mm) |
| Wheelbase | 4.55 ft (1,385 mm) |
| Max Lifting Height | 3.83 m (12.6 ft) standard |
Weight 2 specs
| Service Weight (Diesel) | 7,262 lb (3,294 kg) |
|---|---|
| Service Weight (LPG 2019-2024) | 6,910 lb (3,134 kg) |
Power / Engine 6 specs
| Engine Model (Diesel) | 4TME92 |
|---|---|
| Engine Power (Diesel) | 39 hp (29.1 kW) |
| Engine Cylinders | 4 |
| Displacement (Diesel) | 2.659 L |
| Max Torque (Diesel) | 143 Nm |
| Engine Power (LPG 2011-2019) | 29.4 kW |
