Hyster H3.0FT Specs
Quick-reference specifications for the Hyster H3.0FT forklift, taken from the manufacturer’s spec sheet.
- Rated capacity/rated load Q1
- 3.0 t
Performance 7 specs
| Drive | LPG |
|---|---|
| Rated capacity/rated load Q1 | 3.0 t |
| Tilt of mast / fork carriage forward / backward | 6 / 5 ° |
| Turning radius Wa | 2277 mm |
| Internal turning radius b | 618 mm |
| Lowering speed with / without load | 0.53 / 0.47 m/s |
| Service brake | Hydraulic |
Dimensions 24 specs
| Load centre distance c | 500 mm |
|---|---|
| Load distance, centre of drive axle to fork x | 483 mm |
| Wheelbase y | 1623 mm |
| Tyre type | Superelastic |
| Tyre size, front | 28 X 9 – 15 |
| Tyre size, rear | 6.50 X 10 |
| Height, mast lowered h | 2195 mm |
| Free lift h | 140 mm |
| Lift h | 3055 mm |
| Height, mast extended h | 3805 mm |
| Height of overhead guard (cabin) h | 2185 mm |
| Cab height (open cab) | 2206 mm |
| Seat height relating to SIP h | 1086 mm |
| Coupling height h | 390 mm |
| Overall length l | 3633 mm |
| Length to face of forks l | 2633 mm |
| Overall width b1/b | 1186 / 1321 / 1601 mm |
| Fork dimensions DIN ISO 2331 s/e/l | 50 X 120 X 1000 mm |
| Fork carriage ISO 2328, class/type A, B | III A |
| Fork carriage width b | 1070 mm |
| Ground clearance, laden, below mast m | 132 mm |
| Ground clearance, centre of wheelbase m | 185 mm |
| Aisle width for pallets 1000 × 1200 crossways Ast | 3960 mm |
| Aisle width for pallets 800 × 1200 lengthways Ast | 4160 mm |
Weight 3 specs
| Service weight | 4612 kg |
|---|---|
| Axle loading with load, front / rear | 6640 / 972 kg |
| Axle loading without load, front / rear | 1823 / 2789 kg |
