Hyster H400HD Specs

Quick-reference specifications for the Hyster H400HD forklift, taken from the manufacturer’s spec sheet.

Performance 8 specs

Load capacity (36″ load center)	40,500 lb
Load capacity (48″ load center)	35,200 lb
Mast tilt, a = forward /b = back	10/12 degrees
Outer turning radius	207 in
Inner turning radius (To C.L. of truck)	80 in
Stability (Comply with ANSI B56.1)	YES
Travel speed with/without load	16.1 / 17.4 mph
Lifting speed with/without load	64.9 / 74.8 ft/min

Lift height (TOF)	212.6 in
Fork dimensions, thickness/width/length	4 x 8 x 96 in
Fork carriage width	105 in
Length to face of forks	226 in
Center Drive Tire to Face of Forks	39.8 in
Overall width	116 in
Height of mast, lowered	174.2 in
Height of mast, extended	277.2 in
Cab height (deduct 2 inch for non-cab option)	132 in
Seat height	84 in
Towing coupling height	34 in
Overall length (with 96 inch forks)	322 in
