Telehandler · JCB
JCB 30-19E Specs
Quick-reference specifications for the JCB 30-19E telehandler, taken from the manufacturer’s spec sheet.
- Gradeability (unladen)
- 21 %
Performance 8 specs
| Lift capacities (with sideshift) | 3000 kg |
|---|---|
| Carriage tilt total | 111 degrees |
| Maximum reach ground level (500mm load centre) | 2230 mm |
| Maximum reach boom horizontal (500mm load centre) | 2390 mm |
| Turning radius | 2525 mm |
| Travel speed (standard) | 18 km/h |
| Gradeability (unladen) | 21 % |
| Park brake type | Hand |
Dimensions 14 specs
| Lift height | 4000 mm |
|---|---|
| Free lift (standard) | 1575 mm |
| Height (boom extended) | 4625 mm |
| Height of overhead guard | 2245 mm |
| Height of operators seat | 1071 mm |
| Length to fork face | 3000 mm |
| Wheelbase | 1800 mm |
| Load centre | 500 mm |
| Ground clearance (lowest point) | 143 mm |
| Ground clearance (wheelbase centre) | 172 mm |
| Fork carriage width | 1200 mm |
| Maximum width of machine | 1295 mm |
| Aisle width 90° stacking 800 x 1200/1000 x 1200 | 4000 mm |
| Tyre size front (standard) | 29 x 10 x 12 |
Weight 1 spec
| Weight unladen | 5040 kg |
|---|
Power / Engine 2 specs
| Engine type | Electric |
|---|---|
| Transmission | Electric |
Hydraulics / Fluids 2 specs
| Working pressure for attachments | 170 bar |
|---|---|
| Oil flow for attachments (standard/high) | 28/70 l/min |
