JCB 35 Specs
Quick-reference specifications for the JCB 35 telehandler, taken from the manufacturer’s spec sheet.
- Operating weight
- 3556 kg
- Gradeability
- 30 degrees
Performance 3 specs
| Travel speed – low | 2.8 kph |
|---|---|
| Travel speed – high | 4.5 kph |
| Gradeability | 30 degrees |
Dimensions 16 specs
| Track length on ground | 1590 mm |
|---|---|
| Undercarriage overall length – rubber | 2048.5 mm |
| Undercarriage overall length – steel | 2048.5 mm |
| Kingpost clearance | 555 mm |
| Tailswing radius (Standard / Heavy counterweight) | 900 / 1000 mm |
| Overall width of superstructure | 1550 mm |
| Height over cab | 2482 mm |
| Ground clearance | 275 mm |
| Track gauge | 1400 mm |
| Width over tracks | 1750 mm |
| Transport length with standard dipper | 4851 mm |
| Track height | 480 mm |
| Counterweight clearance | 563 mm |
| Track width rubber (STD) | 300 mm |
| Track width steel | 300 mm |
| Excavator/track main relief pressure | 250 bar |
Weight 4 specs
| Ground bearing pressure (400mm tracks) | 0.316 kg/cm2 |
|---|---|
| Operating weight | 3556 kg |
| Shipping weight | 3371 kg |
| Heavy counterweight | 246 kg |
Power / Engine 7 specs
| Fuel | Diesel |
|---|---|
| Gross power ISO 14396 | 18.4 kW (@ 2200 rpm) |
| Net power | 15.9 kW (@ 2000 rpm) |
| Gross torque ISO 14396 | 91.9 Nm (@ 1600 rpm) |
| Displacement | 1662 cc |
| Starter motor | 2 kW |
| Battery | 12 V / 80 Ah |
Hydraulics / Fluids 7 specs
| Pump | 38 cc |
|---|---|
| Nominal output @ 2000rpm | 76 lpm |
| Slew main relief pressure | 216 bar |
| Auxiliary hydraulic pressure (Low) | STD: 190 bar |
| Auxiliary hydraulic pressure (High) | STD: 190 bar |
| Auxiliary hydraulic flow (Low) | 30 lpm |
| Auxiliary hydraulic flow (High) | 70 lpm |
