JCB 520 Specs
Quick-reference specifications for the JCB 520 telehandler, taken from the manufacturer’s spec sheet.
- Lift Capacity at Full Height
- 4000 lb1814 kg
- Reach at Maximum Lift Height
- 2-11 ft-in.9 m
- Weight
- 9700 lb4400 kg
Performance 5 specs
| MAX PAYLOAD | 4,000 lb (1,814 kg) |
|---|---|
| Lift Capacity at Full Height | 4000 lb (1814 kg) |
| Lift Capacity at Full Reach | 2000 lb (900 kg) |
| Reach at Maximum Lift Height | 2-11 ft-in (.9 m) |
| Maximum Reach Forward | 8-6 ft-in (2.6 m) |
Dimensions 2 specs
| MAX LIFT HEIGHT | 13 ft 3 in (4.0 m) |
|---|---|
| Maximum Lift Height | 13-3 ft-in (4.0 m) |
Weight 1 spec
| Weight | 9700 lb (4400 kg) |
|---|
Power / Engine 1 spec
| MAX HORSEPOWER | 49 hp (37 kW) |
|---|
