Telehandler · JCB
JCB 530-70 Specs
Quick-reference specifications for the JCB 530-70 telehandler, taken from the manufacturer’s spec sheet.
- Lift capacity
- 3,000 kg
- Reach at maximum lift height
- 1.0 m
- Maximum forward reach
- 3.83 m
- Operating weight (with GP shovel)
- 7825 kg
Performance 5 specs
| Lift capacity | 3,000 kg |
|---|---|
| Lift capacity to full height | 2500 kg |
| Lift capacity at full reach | 1250 kg |
| Reach at maximum lift height | 1.0 m |
| Maximum forward reach | 3.83 m |
Dimensions 15 specs
| Lift height | 7.0 m |
|---|---|
| Maximum placing height | 6.3 m |
| Maximum dump height | 5.8 m |
| Shovel roll-back angle (at full height) | 37 degrees |
| Shovel dump angle (at full height) | 44 degrees |
| Overall height | 2.62 m |
| Overall width (over tyres) | 2.36 m |
| Inside width of cab | 0.79 m |
| Front track | 1.99 m |
| Wheelbase | 2.54 m |
| Overall length to front tyres | 4.13 m |
| Overall length to front carriage | 4.92 m |
| Ground clearance | 0.39 m |
| Front wheel centre to carriage | 1.42 m |
| Outside turn radius (over tyres) | 4.85 m |
Weight 2 specs
| Operating weight (with GP shovel) | 7825 kg |
|---|---|
| Operating weight (with forks) | 7510 kg |
Power / Engine 6 specs
| Displacement | 4.8 litres |
|---|---|
| No of cylinders | 4 |
| Gross power @ 2200rpm | 76 hp (56 kW) |
| Max. torque @1100rpm | 31.6 kgm (310 Nm) |
| Engine oil | 14.2 litres |
| Transmission oil | 18 litres |
Hydraulics / Fluids 8 specs
| Operating system pressure | 245 bar |
|---|---|
| Main hydraulics | 103 l/min |
| Boom raise | 9.9 Seconds |
| Boom lower | 7.9 Seconds |
| Fuel tank | 110 litres |
| Hydraulic tank | 120 litres |
| Front axle oil | 21 litres |
| Rear axle oil | 11 litres |
