Linde H150 Specs
Quick-reference specifications for the Linde H150 forklift, compiled from published specifications.
- Maximum Lift Height
- 275.5 in7.0 m
- Operating Weight
- 42,957 lb19,485 kg
Performance 11 specs
| Load Capacity | 33,069 lb (15,000 kg) |
|---|---|
| Max Fork Height | 12.14 ft (3.70 m) |
| Maximum Lift Height | 275.5 in (7.0 m) |
| Max Speed | 16.4 mph (26.4 kph) |
| Lift Speed | 88.59 ft/min (0.27 m/s) |
| Lower Speed | 98.43 ft/min (0.30 m/s) |
| Load Center | 23.63 in (60 cm) |
| Turning Radius | 13.75 ft (4.19 m) |
| Mast Tip Forward | 5 degrees |
| Mast Tip Rear | 10 degrees |
| Max Fork Spread | 88.59 in (2.25 m) |
Dimensions 6 specs
| Length to Fork Face | 15.75 ft (4.80 m) |
|---|---|
| Overall Width | 8.24 ft (2.51 m) |
| Overall Height – Mast Lowered | 12.05 ft (3.67 m) |
| Height to Top of Overhead Guard | 10.22 ft (3.12 m) |
| Wheelbase | 9.68 ft (2.95 m) |
| Ground Clearance | 10.36 in (26.31 cm) |
Weight 1 spec
| Operating Weight | 42,957 lb (19,485 kg) |
|---|
Power / Engine 3 specs
| Engine Model | QSB 6.7 |
|---|---|
| Power | 132.1 hp (98.5 kW) |
| Number of Cylinders | 6 |
Hydraulics / Fluids 1 spec
| Tire Type | Pneumatic 12.00X20/20 PR |
|---|
