Linde R14X Specs

Quick-reference specifications for the Linde R14X forklift, taken from the manufacturer’s spec sheet.

Performance 10 specs

Load capacity/Load Q	1.4 t
Height of reach legs h	245 mm
Reach travel l	170 mm
Turning radius Wa	1335 mm
Travel speed, with/without load	14 / 14 km/h
Lifting speed, with/without load	0.44 / 0.7 m/s
Lowering speed, with/without load	0.55 / 0.45 m/s
Reach speed, with/without load	0.1 / 0.105 m/s
Acceleration time, with/without load	5.8 / 5.0 s
Service brake	Electric/hydraulic

Load centre distance c	600 / 500 mm
Axle centre to fork face x	46 mm
Wheelbase y	1130 mm
Tyres	Polyurethane
Tyre size, front	Ø 343 x 135
Tyre size, rear	Ø 230 x 140
Track width, rear b	1072 mm
Height of mast, lowered h	2455 mm
Free lift h	1541 mm
Lift h	5655 mm
Height of mast, extended h	6614 mm
Height of overhead guard (cabin) h	2190 [2365] mm
Height of seat/stand on platform h	970 / 1130 mm
Overall length l	2444 mm
Length to fork face l	1294 mm
Overall width b1/b	1270 / 1270 mm
Fork dimensions DIN ISO 2331 s/e/l	40 x 80 x 1150 mm
Fork carriage to ISO 2328, class/type A, B	2A
Width of fork carriage b	710 mm
Fork spread b	296 / 690 mm
Distance between wheel arms/loading surfaces b	930 mm
Ground clearance, centre of wheelbase m	70 mm
Aisle width for pallets 1000 × 1200 crossways Ast	2662 mm
Aisle width with pallet 800 x 1200 along forks Ast	2756 mm
Length of chassis l	1451 mm

Service weight	3620 kg
Axle load without load, front/rear	1960 / 1660 kg
Axle load, fork outreached, with load, front/rear	910 / 4110 kg
Axle load, fork retracted, with load, front/rear	1150 / 3870 kg

Drive motor rating S2 60 min	6.5 kW
Lift motor rating at S3 15%	14 kW
Battery according to DIN 43531/35/36 A,B,C,no	43 531 / A
Battery weight (± 5%)	720 kg
Type of drive unit	Electronic/stepless

Operating pressure for attachments	180 bar
Oil flow for attachments	25 l/min
