Linde T25AP Specs
Quick-reference specifications for the Linde T25AP forklift, taken from the manufacturer’s spec sheet.
- Rated capacity/rated load Q
- 2.5 t
- Max. gradeability, laden/unladen
- 8.0/20.0 %
Performance 9 specs
| Rated capacity/rated load Q | 2.5 t |
|---|---|
| Height drawbar in driving position min./max. h | 1149/1357 mm |
| Turning radius Wa | 2861/2931 mm |
| Travel speed, laden/unladen | 11/14 km/h |
| Lifting speed, laden/unladen | 0.04/0.06 m/s |
| Lowering speed, laden/unladen | 0.07/0.06 m/s |
| Max. gradeability, laden/unladen | 8.0/20.0 % |
| Service brake | Electric/hydraulic |
| Sound pressure level LpAZ (at the operator’s seat) | 69 dB (A) |
Dimensions 15 specs
| Load centre distance c | 1200 mm |
|---|---|
| Load distance, centre of drive axle to fork x | 1762/1832 mm |
| Wheelbase y | 2208/2278 mm |
| Tyre size, front | Ø 254 × 102 |
| Tyre size, rear | 2x Ø85 × 80 |
| Additional wheels (dimensions) | 2x Ø 125 × 60 |
| Lift h | 115 mm |
| Height, lowered h | 85 mm |
| Overall length l | 3499 mm |
| Length to fork face l | 1099 mm |
| Overall width b1/b | 790 mm |
| Fork dimensions DIN ISO 2331 s/e/l | 55/165/2400 mm |
| Fork spread b | 520/540/560/680 mm |
| Ground clearance, centre of wheelbase m | 30/150 mm |
| Aisle width for pallets 1000 × 1200 crossways Ast | 3706/3754 mm |
Weight 3 specs
| Service weight | 1010 kg |
|---|---|
| Axle loading, laden front/rear | 1470/2040 kg |
| Axle loading, unladen front/rear | 853/157 kg |
Power / Engine 5 specs
| Drive motor rating S2 60 min | 3 kW |
|---|---|
| Lift motor rating at S3 15% | 2.2 kW |
| Battery according to DIN 43531/35/36 A,B,C,no | 43 535 B/3PzS |
| Battery weight | 327 kg |
| Type of drive unit | AC control |
