Manitou MHT12330 Specs
Quick-reference specifications for the Manitou MHT12330 telehandler, taken from the manufacturer’s spec sheet.
Performance 8 specs
| Max. capacity at 1200 LC | 72,752 lb (33,000 kg) |
|---|---|
| Max. outreach | 21 ft 7.8 in (6.6 m) |
| Tires | 21.00/R35 |
| Frame Leveling | +/- 8° |
| Laden drawbar pull | 28 400 daN |
| Turning radius at tires | 23 ft 1.9 in (7.06 m) |
| Noise at driving position (LpA) | 80 dB |
| Environmental noise (LwA) | 107 dB |
Dimensions 7 specs
| Max. lifting height | 39 ft (11.9 m) |
|---|---|
| Overall width | 29 ft 5.5 in (8.98 m) |
| Overall height | 11 ft 9.3 in (3.59 m) |
| Overall length to carriage | 35 ft 4 in (10.77 m) |
| Ground clearance | 23.2 in (0.59 m) |
| Inside tire width | 5 ft 10.4 in (1.79 m) |
| Standard forks (length x width x thickness) | 7 ft 10.5 in x 9.8 in x 4.3 in (2400 x 250 x 110 mm) |
Weight 1 spec
| Unladen weight (with forks) | 108,026 lb (49,000 kg) |
|---|
Power / Engine 6 specs
| Engine | DEUTZ |
|---|---|
| Power | 245 HP (180 kW) |
| Max. torque | 737.5 lbf-ft (1000 Nm) @ 1450 rpm |
| Batteries | 24 V – 2 x 12 V 120 Ah – 850 A |
| Transmission | Hydrostatic with powershift 3/3-HSE 2+3 |
| Fuel | 158.5 gal (600 l) |
Hydraulics / Fluids 2 specs
| Load sensing Pump | 81.9 gal/min ((310 l/min) – 5,076 psi (350 bar)) |
|---|---|
| Hydraulic oil | 105.5 gal (570 l) |
