Manitou MT932 EASY Specs

Quick-reference specifications for the Manitou MT932 EASY telehandler, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Performance 10 specs

Max. outreach	6.35 m
DEUTZ – STAGE 3B-Final Tier IV	10°
Laden drawbar pull	7320 daN
Steering mode	4 wheel steer – 3 steering modes
Unladen weight (withforks)	7145 kg
Turning radius (overtyres)	3.80 m
Carriage rotation (crowd/dump)	13° / 134°
Noise at driving position (LpA)	78 dB
Environmental noise (LwA)	104 dB
Vibration to whole hand/arm	<2.50 m/s²

Dimensions 9 specs

Compact dimensions	l 4.70 m x w 2.34 m x h 2.30 m
Max. lifting height	9.00 m
Front wheel centre to carriage	1.13 m
Wheelbase	2.81 m
Overall length to carriage	4.70 m
Overall width of cab	0.80 m
Inside tyre width	1.93 m
Overall width	2.34 m
Standard forks (lengthxwidthxthickness)	1200 x 125 x 45 mm

Power / Engine 1 spec

Max. torque	330 Nm

Hydraulics / Fluids 1 spec

Hydraulic oil	128 l
