Aerial Lift · Snorkel
Snorkel MB26J Specs
Quick-reference specifications for the Snorkel MB26J aerial lift, taken from the manufacturer’s spec sheet.
- Platform capacity (SWL)
- 215 kg
- Max. working height
- 9.8 m
- Weight
- 3,175 kg
- Gradeability
- 25%
Performance 12 specs
| Max. working height | 9.8 m |
|---|---|
| Max. working outreach | 3.0 m |
| Platform capacity (SWL) | 215 kg |
| Max. wind speed | 12.5 m/s |
| Max. drive speed (stowed) | 3.2 km/h |
| Max. drive speed (elevated) | 0.48 km/h |
| Jib arc | 130º |
| Mast rotation (non-continuous) | 360º |
| Raise/lower time | 56/27 sec |
| Gradeability | 25% |
| Inside turning radius | 0.3 m |
| Outside turning radius | 2.1 m |
Dimensions 8 specs
| Max. platform height | 7.8 m |
|---|---|
| Platform size | 0.78 m x 0.73 m |
| Overall width (A) | 1.0 m |
| Stowed length (C) | 2.8 m |
| Stowed height (B) | 1.98 m |
| Ground clearance | 100 mm |
| Max. drive height | 7.8 m |
| Jib length | 1.4 m |
Weight 1 spec
| Weight | 3,175 kg |
|---|
