Snorkel SR9244 Specs
Quick-reference specifications for the Snorkel SR9244 aerial lift, taken from the manufacturer’s spec sheet.
- Max. lift capacity
- 9,260 lb
- Weight
- 24,581 lb
Performance 7 specs
| Max. lift capacity | 9,260 lb |
|---|---|
| Max. forward reach | 31 ft 2 in |
| Max. drive speed | 18 mph |
| Raise/lower time | 13/9.5 sec |
| Frame leveling | 11° |
| Outside turning radius | 13 ft 8 in |
| Tires | 405/70-24 |
Dimensions 6 specs
| Max. lift height | 44 ft 4 in |
|---|---|
| Overall width | 7 ft 6 in |
| Stowed height | 8 ft 5 in |
| Length to fork face | 21 ft 2 in |
| Wheelbase | 9 ft 8 in |
| Ground clearance | 14 in |
Weight 1 spec
| Weight | 24,581 lb |
|---|
Power / Engine 1 spec
| Fuel capacity | 31.7 gal |
|---|
Hydraulics / Fluids 3 specs
| Hydraulic flow (per minute) | 32 gal |
|---|---|
| Hydraulic pressure | 3,336 psi |
| Hydraulic oil capacity | 39.5 gal |
